Stall Progress

by: spacepodlife

This displays a series of diagrams illustrating the progression of an airfoil's stall. Each diagram shows the angle of attack increasing, resulting in a decrease in lift and ultimately leading to a stall. There are five distinct diagrams, each showing different stages of the stall process. The first diagram depicts the initial stage where the angle of attack is low, and the airfoil generates sufficient lift for flight. The second diagram shows an increase in the angle of attack, causing a decrease in lift but still maintaining flight. In the third diagram, the angle of attack continues to rise, leading to a stall as the airfoil loses its ability to generate lift. The fourth and fifth diagrams show the progression of the stall, with the angle of attack increasing further until it reaches a critical point where the airfoil is no longer able to maintain flight.
